LIGHT SOURCE TYPE
- Souce type:
- RGBW LEDs
- Power:
- 40W (x19)
- Colour Temperature:
- 2400 to 9500 K
- CRI:
- Up to 70
- LED life expectancy: 50000 hrs L70**It may vary depending on various factors, as type of use and environment
PHOTOMETRIC DATA
- Zoom range:
- 4.7° – 46°
- Lumen Output:
- 13500 (Integrating sphere)
- Optical system:
- Patented 19 lens system
NOISE LEVEL
- Controled by: Able to control linearly the speed of the fans
- Fixed preset:
- Auto mode: 42.3 dB
- Silent Mode: 39.4 dB
- Constant Mode: 44.7dB
- Theatre mode: 39.3 dB
CONTROL and CONNECTIONS
- Personalities:
- Basic engine: 21/22/35/36/37
- Pixel engine: 57/76
- Control Protocol:
- DMX, Art-Net, RDM, sACN, CRMX lumen radio
- Connectors:
- Locking 5 pin XLR IN/THRU
- Ethernet port:
- RJ45 IN
- Power connector:
- PowerCon True1 IN/OUT
- Web Server:
- Built In
- CloudIO:
- Fully compatible
- On-field calibration for color consistency
DYNAMIC EFFECTS
- Colours:
- Built-in macros with enhanced pixel control
- Preset colors
- Dedicated channel for color temperature setting
- White CT Emulation 2500-8000K
- RGBW auto-tuning to lamp CT Emulation
- Tungsten Lamp Emulation
- Rotating Effects:
- Bi-directional rotating front lenses
- Movement:
- Tilt: 248° (16 bit)
- Pan: 540° (16 bit)
- Automatic repositioning
- Mechanical Pan/Tilt lock for safe transportation and maintenance
- Beam:
- Beam edge softening control (in wash mode)
- Dimmer/Shutter:
- 0-100% linear electronic dimmer
- Adjustable speed stop/strobe effect with instantaneous blackout
- Slow strobe: 1 flash/sec
- Fast strobe: 25 flash/sec
- High resolution electronic dimmer – 24 bit, 4 curves
HARDWARE and SOFTWARE
- Long life self-charging battery
- Display graphic LCD backlit B/W display
- Firmware upload from another fixture
- Firmware upgrade via Web Server
- Diagnostic
- DMX monitoring
- Remote access through RDM
HOUSING
- Aluminium and steel structure with plastic covers
- Two side handles for transportation
- IP66 protection rate
- Working in any position
- Hanging system: with fast-lock Omega clamps (1/4 turn) on the base
- Optional safety chain
- Marine grade protection
ELECTRICAL
- Operating Voltage:
- 100-240V, 50/60 Hz
- Power Supply:
- Electronic auto range with active PFC
- Max Power consumption:
- 680W
THERMAL SPECIFICATION
- Max ambient temperature:
- 45°C (113°F)
- Min ambient temperature:
- -20°C (-4°F)
- Max temp. of the ext. surface:
- 90°C (194°F)
- Total heat dissipation:
- 2596 BTU/hr ±10% / 2736 kJ/hr ±10%
SAFETY SPECS
- Minimum distance of illuminated objects 0.2 m (8’’)
- Minimum distance from flammable materials 0.2 meters (8”)
- Thermally protected power supply (overheating and cooling failure)
- 5×20 delayed fuse
- Forced ventilation with axial fans
COMPLIANCE
- CE Marking (in conformity to the following):
- 2014/53/EU – Radio Equipment Directive (RED)
- 2011/65/EU – Restriction of the use of certain hazardous substances (RoHS)
- 2009/125/EC – EcoDesign requirements for Energy-related Products (ErP)
- UKCA conforms to UK regulations:
- S.I. 2017 N.1206
- S.I. 2012 N.3032
- S.I. 2021 N.745
- cMETus Listed:
- UL1573
- CSA C22.2 N. 166:15
PACKAGING
- Carton box + Polystyrene
- Carton box + Foam shell
- Flight case + Foam shell (4 positions)
WEIGHT – SIZE
- Weight:
- 27,8 Kg
- 61,3 lbs
- Base dimensions:
- 295 x 390 mm
- 11.61 x 15,35 in
- Height with vertical head (h):
- 573 mm
- 22,56 in
- Distance between two fixtures:
- 600 mm
ACCESSORIES
- Omega bracket: 2×183102/805 (Included)
- ETL Power: CAB02B/802 (Included)
- Foam shell: F21342/001 (Optional)
- Flight case (4 positions) + Foam shell: CF1026F (Optional)
- CRMX antenna extension: ANT004 (Optional)
- Safety Chain: 105041/001 (Optional)
- Clamp: C21070 (Optional)
